Horizontal band saw is composed of a saw frame, a parallelogram adjustment device or a four-screw adjustment device, track, and a lifting bracket. When the machine is working, the wood is fixed, the track is stably fixed on the wood, and the saw is installed on the track. Adjust the thickness of the processed wood so that the saw can make a plane cut along the wood.
Horizontal band saw is composed of a saw frame, a parallelogram adjustment device or a four-screw adjustment device, track, and a lifting bracket. When the machine is working, the wood is fixed, the track is stably fixed on the wood, and the saw is installed on the track. Adjust the thickness of the processed wood so that the saw can make a plane cut along the wood.
Horizontal band saw is not only easy to process large and extra-long wood, but also has guaranteed quality. It is widely used in sawmills and mountain timber harvesting sites for mobile processing.
| Technical Parameter | MJ700E | MJ1000E | MJ1300E | MJ1600E |
|---|---|---|---|---|
| Max. Sawing Wood Width | 700mm | 1000mm | 1300mm | 1600mm |
| Max. Sawing Wood Length | 4500mm | 4500mm | 4500mm | 4500mm |
| Saw Wheel Diameter | 700mm | 700mm | 700mm | 700mm |
| Sawing Wood Thickness | 10-200mm | 10-300mm | 10-300mm | 10-300mm |
| Main Electric Motor | 15KW | 18.5KW | 22KW | 30KW |
| Lifting Electric Motor | 1.5KW | 1.5KW | 1.5KW | 1.5KW |
| Band Saw Blade Length | 5050mm | 6100mm | 6600mm | 7100mm |
| Machine Length | 5800mm | 5800mm | 5800mm | 5800mm |
| Total Weight | 800kg | 1100kg | 1300kg | 1500kg |
| 20 FCL Container Can Load | 2 Sets | 2 Sets | 2 Sets | 2 Sets |
Horizontal band saw machine adopts manual or automatic cutting, and can saw round wood, square wood, semi-circular wood and other raw materials, and can saw various special-shaped wood. It can save labor and reduce the labor intensity of the staff.
Horizontal band saw is strong and durable, energy-saving and environmentally friendly, labor-saving and material-saving and a high degree of automation, making it a wood processing equipment in the field of woodworking machinery.
